Power

• VA 6000
• W 6000

Input

• Rated voltage* 110–280 Vac
• Frequency 45–70 Hz
• Power factor >0.99

Output

• Rated voltage 200/208/220/230/240 Vac selectable
• Voltage distortion <2% with linear load, <7% with distorting load
• Voltage stability ±1%
• Frequency 50/60 Hz (selectable)
• Frequency stability ≤ 0.2% (free running)
• Power factor 1
• Crest factor 3:1
• Waveform Pure sine wave
• Output sockets Terminal blocks

Efficiency

• VFI mode Up to 94%
• ECO mode Up to 98%

General

• Dimensions (WxDxH) mm 240x700x513
• Weight with / without batteries (kg) 26/60.4
• Alarms Audible and visual alarm alerts for: power failure, low battery, bypass transfer, and UPS fault.
• Protection Overload, overheating, short circuit, deep discharge, battery overcharging.
• Operating mode Multi-mode: VFl, ECO, frequency converter (CVCF)
• Cold start from the battery without mains power Included

Battery

• Uptime with internal battery (in min) 12 / 4
• Part Number
  00-00483
• Product Name
  UPS-EP006-11-I16-T
