Description

Features and benefits

• 5 GHz Wi-Fi 6
  Dual concurrently working bands and 1500 Mbps wireless speed bring extraordinary online experiences.
• Steering clients to the optimal one of the dual bands
  It allows one-button connection to the 2.4G and 5G bands and steers your mobile phones to the optimal band automatically without
  manual selection.
• Intelligent management from an APP
  From an APP, you can complete network settings configuration and network speed optimization with ease, and perform various operations
  by a simply button press or selection.
• Tough Testing Standards
  H3C works with international authoritative test instrument manufacturers such as Octoscope, Spirent, and Ixia to simulate a variety of real
  household scenarios and limits, ensuring that the router runs steadily under different conditions.

Technical specifications

• Port
  4 × 10/100/1000BASE-T Ethernet ports
• Antenna
  4 × external 5 dBi omnidirectional antennas
• LED
  System status LED on the rear
• Dimensions (H × W × D)
  180 × 195 × 57.3 mm (7.09 × 7.68 × 2.26 in)
• Power consumption
  ≤ 12 W
• Cooling
  Passive cooling
• Certification
  WEEE / RoHS
• Wireless roaming
  IEEE 802.11k/v
• MU-MIMO
  Upstream and downstream MU-MIMO
• Wireless protocol
  2.4GHz: 802.11n/g/b
  5GHz: 802.11ax/ac/n/a
• Spatial streams
  2.4GHz 2×2 MIMO
  5GHz 2×2 MIMO
• Wireless bandwidth
  2.4G HT20/HT40
  5G HT20/HT40/HT80
• Wireless rate
  Simultaneous dual-band: 1501 Mbps, including 300 Mbps on the 2.4GHz band and 1201 Mbps on
  the 5GHz band.
• Part Number
  H3C Magic NX15-UK
