Description

Features and Benefits

• Waterblocking technology
  OSP (outdoor) applications
• All-dielectric cable construction
  Requires no grounding or bonding
• UV- and microbe-resistant
  Can be installed in ducts or conduits
• Dry cable core by means of water swellable elements
  Allows efficient and craft-friendly cable preparation in
  outdoor or indoor/outdoor applications
• Small diameter and bend radius
  Easy installation in space-constrained areas
• TB3 tight-buffered construction
  Easy and consistent stripping up to 10 cm
• Silicon-free outer jacket
  The cable jacket and the outer jacket of subunits (not
  valid for 900µm tight buffers)are free of harmful to paint
  structures

Standards

• Flame Test Method
  Flame retardant to IEC
  60332-1-2 (single cable)
  Flame retardant to IEC
  60332-3-24 (bunch of ca
  bles)
  Low Smoke to IEC 61034
  and Zero Halogen to IEC
  60754-1
  Non Corrosive to IEC
  60754-2
• Waterblocking
  IEC 60794-1-2F5

General Specifications

• Environment
  Indoor/Outdoor Universal Cable
• Application
  Direct Buried, Duct, Vertical Riser, General Purpose
  Horizontal
• Cable type
  Tight buffered
• Product type
  Dielectric
• Flame rating
  LSZH™/FRNC
• Fibre Category
  SM (OS2)
• Coding according to EN 60794-1-1 (DIN VDE 0888-100-1)
  U-VQ(ZN)H
• Part Number
  002E8X-32125E2G
