Description

Features and Benefits

• Compliance with the new Class EA and IEEE 802.3an
• Supports for PoE, PoE+ and 4PPoE applications
• Providing easy and fast installation without tools
• Re-termination possible for multiple usage
• The connector can be used with flex wire cables AWG
  23-27 and solid wire cables AWG 23-26

Specifications

Category
6A

Halogen-free
Yes

Bandwidth
500MHz

Standards

• RoHS
  Free of hazardous substances according to RoHS 2011/65/EU
• Flame retardance
  Class UL94 V-0
• Transmission performance link
  Class EA (ISO/IEC 11801 Ed. 2.2 2011)
• Corning Recommendations
  Recommended cable diameter is 5.5 mm – 8.5 mm
• Component Standard
  ANSI/TIA/EIA-568-B.2-10IEC 60603-7-5:2010
• Part Number
  CAXKSS-00100-C001
