FIBER HSG 06 LC DUP HYBRID B

SKU: LAN1-12AD-HYBRID-L-B

101,802

DESCRIPTION

The Everon® LAN1 Fibre Housing family was designed for various applications in 19-racks and main distribution frames. The fixed or sliding housings can be equipped with industry common adapter types in different fibre categories and are suitable for direct field termination, fusion splicing with pigtails as well as preterminated solutions. The four back openings accommodate cable glands. Additional brackets for cable strain relief for FTTD/FTTO applications or U-Clips for Plug & Play™ and EDGE™ trunks can be mounted at the backside. The space-optimized interior makes it easy to work with ongoing moves, adds and changes (MACs), thus reducing the risk of network disruptions.

Product Description

Features and Benefits
  • Easy to remove top cover
    No tools needed
  • Housing made of aluminium
    Lightweight, but robust
  • Quick-mount feature
    Allows single-person mounting of housing
  • Accomodate different termination methods
    Pigtail splicing, field connectorisation, preterminated
    cables, Plug&Play™ or EDGE™ trunks can be installled in
    the same housing
  • Low installation depth
    Mountable in shallow cabinets or racks
  • Multiple labelling options
    Port numbering above and below adapter modules or
    customised labels
Specifications
  • Product type
    Housings
  • Access type
    Front, top, rear
  • Mounting Type
    Rack-mount
Standards
  • RoHS
    Free of hazardous substances according to RoHS 2011/65/EU
Design
  • Lockable
    No
  • Fibre count
    12
  • Splice tray type
    No Splice Trays
  • Housing material
    Aluminum
  • Additional cable number reached w/accessories
    4
  • Max. cable number in basic unit w/accessories
    4
  • Cable entry type
    Prepunched circular
  • Number of pigtails
    0
  • Number of splice trays
    0
  • Adapter colour front
    Turquoise
  • Adapter type front
    LC PC duplex shuttered
  • Splice protectors type
    Without organizer and protectors
  • Number of adapters
    6
  • Part Number
    LAN1-12AD-HYBRID-L-B
  • Product Name
    FIBER HSG 06 LC DUP HYBRID B



Out of stock
