Description

Features and benefits

Multiple working modes
The switch can operate in standard, isolation, aggregation, or clone mode and supports one-key switching of the working mode

Green
This switch is energy efficient. Without using fan trays, it is noiseless.

High performance
With a buffer sharing architecture, the switch multiplies the available buffering space for each port, greatly enhancing the
forwarding performance especially in the event of unexpected and sudden traffic bursts.

High reliability
Built with a highly reliable power supply.

Technical specifications

• Dimensions (H × W × D)
  44 × 294 × 179 mm (1.73 × 11.57 × 7.05 in)
• Ports
  24 × 10/100/1000BASE-T copper ports (2 uplink ports)
• Operating mode
  Standard
  Isolation
  Aggregation
  Clone
• MAC address entries
  8K
• Switching capacity
  48 Gbps
• Forwarding capacity
  35.7 Mpps
• Packet caching
  4 Mbit
• Switching mode
  Store-and-forward switching
• Power
  100 to 240 V AC
• Auto-MDI/MDIX
  Yes
• Cooling method
  Natural cooling
• Operating temperature/storage temperature
  0°C to 40°C (32°F to 104°F)/–40°C to +70°C (–40°F to +158°F)
• Certifications
  CE,RoHS
• Part Number
  H3C Magic BS224-UK
