Features and benefits

• Multiple working modes
  The switch can operate in standard and isolation working modes and supports one-key switching of the working mode.
• High performance
  With a buffer sharing architecture, the switch multiplies the available buffering space for each port, greatly enhancing the
  forwarding performance in the event of unexpected and sudden traffic bursts.
• High reliability
  Integrating enterprise-level lightning protection circuit into the switch protects the switch from lightning strikes and ensures
  reliable operation of the switch.

Technical specifications

• Dimensions (H × W × D)
  27 × 155 × 58 mm (1.06 × 6.10 × 2.28 in)
• Ports
  8 × 10/100/1000BASE-T copper ports
• Operating mode
  Standard
  Isolation
• MAC address entries
  4K
• Switching capacity
  16 Gbps
• Forwarding capacity
  11.9 Mpps
• Packet buffering
  1.5 Mbit
• Switching mode
  Store-and-forward switching
• Power
  12 V DC, 0.5 A
• Auto-MDI/MDIX
  Yes
• Cooling method
  Natural cooling
• Certifications
  CE,RoHS
