Description

GENERAL DATA

• Output rated power 2000VA /1800W
• Output power factor 0,9
• Topology Online double conversion
• Internal Batteries YES
• Parallel Configuration N.A.

INPUT

• Voltage range 110~300 Vac (Single + G)
• Frequency range 45-65Hz (auto sensing)
• Input power factor ≥ 0.99 @ 100% linear load
• Input Current Distorsion ≤ 6% (full load)

OUTPUT

• Output voltage 220/230/240 Vac (Single + G)
• Output voltage distortion <3%@100% Linear Load; <5% @100% Non-Linear Load
• Output voltage regulation ±1%
• Frequency range ±1Hz or ±3Hz (selectable)
• Crest factor ‘3:1
• Output waveform Pure sine wave
• Overload Capacity Inverter
  <105%continuous
  106-120% for 30 seconds transfer to bypass.
  121-150% for 10 seconds transfer to bypass.
• Part Number
  00-00434
• Product Name
  UPS-EP002-11-I06-3US
• Part Number
  00-00434
• Product Name
  UPS-EP002-11-I06-3US
