Description

General

• Dimensions (WxDxH) mm 192 x 470 x 250
• Weight (kg) 22.2
• Alarms Audible and visual alarm alerts for: power failure, low battery, bypass transfer, and UPS fault.
• Protection Overload, overheating, short circuit, deep discharge, battery overcharging.
• Operating mode Multi-mode: VFl, ECO, Constant voltage constant frequency (CVCF) output.
• Cold start from the battery without mains power Included

Battery

• Uptime with internal battery (in min) 50% load 14 / 100% load 5
• Charging time (90%) 4–6 hours

Efficiency

• VFI mode Up to 92%
• ECO mode Up to 96.5%

Input

• Rated voltage* 110–300 Vac
• Frequency 44–66 Hz
• Power factor >0.98

Output

• Rated voltage 200/208/220/230/240 Vac
• Voltage distortion <3% with linear load I, <7% with distorting load
• Voltage stability ±1%
• Frequency 50/60 Hz (selectable)
• Frequency stability ±1 Hz or ±3 Hz (selectable)
• Power factor 0.9
• Crest factor 3:1
• Waveform Pure sine wave
• Output sockets 4xIEC-C13 / 2 Schuko

Power

• VA 2000
• W 1800
• Part Number
  00-00481
• Product Name
  UPS-EP002-11-I06-T
